Thank you for using NI-488.2 for Windows, Version 2.5.2.

The 488.2V4 GPIB driver for controlling test instruments fully supports 32- and 64-bit Windows operating systems as well as 64-bit programs and includes a 64-bit DLL for executing 64-bit programs.

  • What driver do I need and where can I find it? NI GPIB hardware uses the NI-488.2 driver. Follow the steps below to identify and download a compatible driver version. To identify a compatible driver version, you need to cross-reference driver support with the following.
  • NATIONAL INSTRUMENTS PCI GPIB DRIVER - This unit has been used. I have no way of testing it, but am confident that it works. With the VISAIC utility, you can speed up application development by learning how to automate measurements with your instruments, uncover GPIB problems, and avoid headaches by identifying malfunctioning instruments.
  • The GPIB Drivers could be located on the ChemStation Software CD-ROM in the GPIB directory. In this case, the drivers are installed by executing the file HPIOLIBS.

This file contains release notes, patent information, and last-minute information for the NI-488.2 for Windows software. Some information in this file may be too recent to be included in the official documentation set.
This readme contains the following main sections:
  • Supported Interfaces
  • Enhancements and Bugfixes

Release Notes

NI-488.2 for Windows, Version 2.5.2, is the latest driver offering from National Instruments. Every attempt has been made to maintain backward compatibility with the installed base of existing NI-488.2 applications.

Windows 2000 Installation

When installing on a Windows 2000 Service Pack 4 system without critical updates, you may encounter an error message, 'SystemRootsystem32DRIVERSgpibprtk.sys device driver could not be loaded. Error Status was 0xc0000034,' during installation. You can ignore this message, as installation will continue normally. To prevent this message from appearing, do either of the following before running the NI-488.2 installation:

  • Remove any GPIB hardware present in the system
  • Install the latest critical updates for Windows 2000 Service Pack 4
More information may be available at our website, ni.com, when you search for KnowledgeBase 45O8JNHR.

Win16 and DOS Support

Win16 and DOS support are not available on Windows Vista and later operating systems.

Upgrades

This driver allows upgrades starting from NI-488.2 for Windows, Version 2.0, on Windows 2000 and XP. To install over software lower than Version 2.0 on Windows 2000 or XP, you must uninstall the lower version first. Because NI-488.2 for Windows, Version 2.5.2, is the first version to support Windows Vista, if you have installed a lower version of NI-488.2 on Windows Vista, you must uninstall it before installing version 2.5.2.

64-Bit Language Interface

At this time, there is no 64-bit language interface to create 64-bit applications. Use the 32-bit language interfaces and examples to create 32-bit applications to run on Windows Vista x64 (64 bit).

You can double-click a PDF or image file to open it by default in Preview. You can also open Preview and select the files you want to view. In the Preview app on your Mac, choose File Open. One advantage of Mac over Windows is that it has a great built-in PDF viewer, referred to as Preview. Windows lacks this application, but there are alternatives out there for Windows OS. This article introduces the best Preview for Windows - PDFelement that not only include the same functionalities as Preview on Mac. Preview pdf for mac download.


Please review the Supported Interfaces and Enhancements and Bug Fixes in Version 2.5.2 sections.

Supported Interfaces

NI-488.2 for Windows, Version 2.5.2, supports the following hardware.
GPIB Interface2000sp4/XPsp2Vista x86 (32 bit)Vista x64 (64 bit)
AT-GPIB/TNT (PnP)YesNoNo
GPIB-ENET/100YesYesYes
GPIB-USB-BYesYesYes
GPIB-USB-HSYesYesYes
NI ExpressCard-GPIBYesYesYes
NI PCIe-GPIBYesYesYes
PCI-GPIBYesYesYes
PCI-GPIB+YesYesYes*
PCI-GPIB/LPYesYesYes
PCI-8212YesYesYes
PCI-8232YesYesYes
PCMCIA-GPIBYesNoNo
PCMCIA-GPIB+YesNoNo
PMC-GPIBYesYesYes
PXI-GPIBYesYesYes
PXI-8212YesYesYes
PXI-8232YesYesYes

* Analyzer functionality is not supported.

Compatible Software

This driver version has been tested with the following software at the time of release.

  • NI-VISA 4.1
  • LabVIEW 7.1, 8.0, 8.2.0, and 8.2.1
  • LabWindows/CVI 8.0 and 8.1
  • Measurement Studio 8.1

This driver should work with versions earlier than those listed above, but the earlier versions have not been tested.

Enhancements and Bug Fixes in Version 2.5.2

Windows Vista

NI-488.2 for Windows, Version 2.5.2, adds support for Windows Vista x86 (32 bit) and Windows Vista x64 (64 bit). Refer to the Supported Interfaces table for the list of hardware supported on Windows Vista.

Usability

This driver includes several usability improvements, including the following:

  • The GPIB Getting Started Wizard is replaced with a new Welcome screen.
  • The Add New Hardware Wizard is replaced with a new Add GPIB-ENET/100 Wizard.
  • The Troubleshooting Wizard is replaced with a new Troubleshooting Utility.
  • Changing GPIB configuration properties is better integrated into Measurement & Automation Explorer.
For more details about these utilities and tools, refer to the NI-488.2 Help.

Power Management

NI-488.2 for Windows, Versions 2.2 through 2.4.x, attempt to prevent the system from going to standby or hibernate if there is an application with an open NI-488.2 handle. To satisfy Windows Vista requirements, this has changed to no longer prevent the system from going to standby or hibernate. After the system returns from standby or hibernate, take the handle offline and open a new handle, because any subsequent calls from the previously opened handle will return the EPWR error code, except for ibonl 0.

.NET Support

This driver adds .NET 2005 language support and .NET 2003 language support fixes via the native .NET API. They are options in the Feature tree during installation.
Note that prior versions of NI-488.2 for Windows offered two options for .NET support to make it easier to update existing applications. The NI-488.2 wrapper interface, which previously was available on the CD in the Microsoft .NET Language Interface directory, has been removed from the current distribution. The NI-488.2 wrapper interface is still available at our Web site, ni.com.

Language Interface and Examples

The Language Interface and Example files have moved from the Program FilesNational InstrumentsNI-488.2Languages directory to the UsersPublicDocumentsNational InstrumentsNI-488.2Languages directory on Windows Vista and the Documents and SettingsAll UsersDocumentsNational InstrumentsNI-488.2Languages directory on Windows 2000 or XP. This change satisfies Windows Vista requirements, when allowing users to save changes or add files to the directory. Note that the NI-488.2 Help incorrectly describes the location for .NET examples.

Analyzer NMI Parity Error

On certain machines, a bluescreen describing an NMI Parity Error appeared on installing a PCI-GPIB+ interface. This has been fixed.

GPIB-USB-HS

GPIB-USB-HS performance has improved and is optimized for whether it is connected to a full-speed or high-speed port.

SRQ

If an event handler was installed to handle service request (SRQ) events, the events could fail to trigger if the session was currently locked exclusively. This has been fixed.

Enhancements and Bugfixes in Version 2.4

New Hardware Support

NI-488.2 for Windows, Version 2.4 adds support for GPIB-USB-HS, NI ExpressCard-GPIB, and a revised version of the PCI-GPIB+ Controller/Analyzer board.

GPIB-USB-A

Support for the obsolete GPIB-USB-A interface is discontinued in this release.

ibcmd and Serial Poll Performance

Driver version 2.3 performance during ibcmd and serial poll calls was lower than version 2.2. This has been fixed and improved over version 2.2.

Documentation

Driver

Documentation has been updated for various features.

Enhancements and Bugfixes in Version 2.3

New Language Support

NI-488.2 for Windows, Version 2.3, adds language support for Chinese (Traditional), Chinese (Simplified), and Korean. This is in addition to English and Japanese languages supported by the previous versions of NI-488.2 for Windows. All Components of this release have been localized with the exception of:

  • NI-488.2 Interactive Control Utility
  • GPIB Analyzer Software
  • Measurement and Automation Explorer (MAX)
  • NI-VISA
  • User documentation

This release also includes new Getting Started documentation in all languages supported, available through the 'View Documentation' utility on the NI-488.2 for Windows CD.

Windows 98/Me

Windows 98/Me support is discontinued in this release.

Microsoft Sysprep Utility

The Sysprep utility would cause a crash in some cases of deployment. This has been fixed.

ibcmda and ibstop

An ibstop call was unable to stop asynchronous ibcmda calls. This has been fixed.

Utilities

Some cosmetic issues with GPIB utilities have been fixed.

Enhancements and Bug Fixes in Version 2.2

AT-GPIB/TNT (PnP)

NI-488.2 for Windows, Version 2.2, adds support for the AT-GPIB/TNT (PnP) interface.

PCI-Express™ Interface for GPIB

NI-488.2 for Windows, Version 2.2, adds support for the NI PCIe-GPIB, a PCI-Express™ Interface for GPIB.

Power Management

NI-488.2 for Windows, Version 2.2, adds the EPWR error code. This error indicates that the interface lost power. This may occur when the system goes to standby or hibernate mode. The NI-488.2 driver attempts to prevent the system from going to standby or hibernate if there is an application with an open NI-488.2 handle.

.NET Support

National Instruments provides two interfaces for developing GPIB-based applications in Microsoft Visual Studio .NET 2003 or later:

  1. the native .NET API
  2. the NI-488.2 wrapper interface

We recommend the native .NET API as the preferred method of developing GPIB .NET applications because of its superior integration into the Microsoft Visual Studio .NET IDE. The native .NET API can be installed from the NI-488.2 CD by selecting it from the custom installation section. It is installed in the National InstrumentsMeasurement Studio subdirectory. Full integrated help for this API is available inside the Visual Studio .NET environment. The NI-488.2 wrapper interface can be found on the CD in the Microsoft .NET Language Interface directory.

Ni Pci-gpib Driver Windows Xp

New ibask option

NI-488.2 for Windows, Version 2.2, adds the IbaSerialNumber option to ibask. This allows customers to query the serial number of the board that they are using. The ibask call will return a 32-bit serial number for supported interfaces. The driver will return with ERR bit set in ibsta, and iberr set to ECAP for unsupported interfaces. This feature is not supported with the Visual Basic language interface. The VB language interface for ibask does not handle unsigned 32-bit numbers.

Gpib

PCMCIA-GPIB

Older National Instruments PCMCIA-GPIB devices would not enumerate properly with the 2.1 driver. This has been fixed.

ibnotify

The driver sometimes would not call the ibnotify callback, or call the ibnotify callback improperly when waiting for RQS. This has been fixed.

ibconfig

The driver would hang if a device-level ibconfig was called with IbcSPollTime, IbcPAD, or IbcSAD when an ibnotify call on the same device descriptor was in progress. This has been fixed.

Memory leak

The driver had a small memory leak when being used by VISA. This has been fixed.

Analyzer

The GPIB Analyzer application would crash when launched with some video cards. This has been fixed.

DOS

Enabling DOS support worked improperly when logging in as a different user that it was enabled as. This has been fixed.

Enhancements and Bug Fixes in Version 2.1

PCMCIA-GPIB

NI-488.2 for Windows, Version 2.1, adds support for the PCMCIA-GPIB interface. Following the precedent of Version 2.0 of the driver, which unified the driver for the PCI, ENET, and USB interfaces, this version ensures that those interfaces along with the PCMCIA-GPIB can function simultaneously with the same driver.

Analyzer

NI-488.2 for Windows, Version 2.1, supports the GPIB analyzer portion of the PCI-GPIB+ and PCMCIA-GPIB+ on the Windows 2000 and XP operating systems. This support was previously only available on Windows NT, 98, and 95.

Enhancements and Bug Fixes in Version 2.0

Installer

NI-488.2 for Windows, Version 2.0, improves the installation experience for the user.

Windows 2000/XP

In the past, there were separate drivers for plug-in interface boards (PCI-GPIB, etc.), the GPIB-ENET family, and the GPIB-USB-A. Only one of these three could be installed and used at any one time. NI-488.2 for Windows, Version 2.0, removes this restriction. All supported interfaces function simultaneously with the same driver.

Pci Gpib Driver Windows 10

Windows 2000/XP

NI-488.2 for Windows, Version 2.0, resolves the issue that prevents users running the software in USER mode (as opposed to ADMINISTRATOR mode).

Internationalized Software Support

Pci-488 Gpib Driver

NI-488.2 for Windows, Version 2.0, offers an improved localized solution in Japanese.

National Instruments Pci Gpib Driver

Win16 and DOS Support

NI-488.2 for Windows, Version 2.0, does not support Win16 applications for Windows Me/9x platforms. Win16 support is available under Windows 2000 and Windows XP. To use these applications under Windows 9x/Me, you must use a previous version of NI-488.2 for Windows. DOS support is available on all operating systems supported by this driver.

Contacting National Instruments

Thank you for your interest in NI-488.2 for Windows. We appreciate communicating with the people who use our products. We are also very interested in hearing about the applications you develop using our products. Our Web site, ni.com, provides advanced support and services and contact information.

Patent Information

For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.

Home > Products > .. > Test System Components & Software [Discontinued] > Discontinued T&M Software and Connectivity Products [Discontinued] > 82350A PCI GPIB Interface Card for Windows [Obsolete]

Enable JavaScript to view product images.

Product Status:Obsolete Service Optionen ansehen
This product is no longer available

No replacement found for this product.

Key Features & Specifications

  • PCI IEEE-488 interface for PCs
  • Built-in buffering for speed
  • Keysight VEE compatibility
  • BASIC for Windows compatibility
  • Microsoft® Languages compatibility
  • SICL/VISA support
  • Dual processor support on Windows NT/2000

Description

The Keysight 82350A is a low-cost, high-performance IEEE-488 interface and software for PCI-based PCs. The 82350A makes it easy to access and control instruments and exchange data. This is a high-speed PCI card with built-in buffering, which de-couples GPIB transfers from the PCI bus transfers. Buffering provides I/O and system performance that is superior to direct memory access (DMA)-up to 750 KB/s.

The 82350A comes with SICL and VISA software for Windows 95/98/Me/NT/2000. This software is compatible with all previous versions of SICL/VISA. The hardware is software configurable and compatible with the plug&play standard for easy hardware installation.

Pci Gpib Card

The GPIB interface card plugs into a PCI slot in the backplane of your PC. Via a GPIB cable, this card connects to GPIB instruments. For VXI applications a GPIB cable connects the card to the command module in Slot 0 of the VXI mainframe.

  • PCI IEEE-488 interface for PCs
  • Built-in buffering for speed
  • Keysight VEE compatibility
  • BASIC for Windows compatibility
  • Microsoft® Languages compatibility
  • SICL/VISA support
  • Dual processor support on Windows NT/2000
